GARNET XS4
CNC Profile Machining Center (4 Axis)
MACHINING LENGTHS
X Axis (Longitudinal) 4000 mm
Y Axis (Lateral) 320 mm
Z Axis (Vertical) 255 mm
A Axis (Head processing angles) -90° / +90°
POSITIONING SPEED
X Axis (Longitudinal) 90 m/min
Y Axis (Lateral) 60 m/min
Z Axis (Vertical) 20 m/min
A Axis (Rotational Movement) 166° /sec
ELECTRICAL
Max. Power 8 kW
Frequency 50-60 Hz
Voltage 400V 3P, N, PE AC
SPINDLE
Max. Power 5.6 kW
Tool holder HSK F50
Cooling type Liquid
Maximum rotation speed 20.000 r.p.m
TOOL STORAGE
Automatic Linear Type Tools Magazine ●
Maximum saw blade diameter in to the storage system 150 mm
Automatic Tools Measuring ●
Maximum tool storage system number 8
CONTROL UNIT
Industrial PC - Touch Screen 15”
Barcode reader ●
Camquix CAM program ●
CadXtract CAD-CAM Production program ○
AIR
Pressure 6-8 Bar
SCREW-CUTTING CAPACITY
M8 - with compressed tapping head ○
PROFILE POSITIONING
Right and left pneumatic profile reference alignment ●
OPERATIONAL AREA
Clamps, standard pcs
Clamps, maximum pcs
4
6
Automatic clamp positioning with the X-axis
Spray-Automatic lubrication in processing area
●
●
Cabinet providing protection in processing zone ●
Automatic Tool cooling system ○
FESTO pneumatic system
Side tunnels
○
●
Additional Clamp
